Cutek Circuits is one of the most trusted PCB design companies in India, delivering end-to-end printed circuit board solutions tailored for performance, reliability, and manufacturability. Our expert team specializes in crafting robust PCB layouts for applications in industrial automation, medical electronics, consumer appliances, automotive systems, defense technologies, and more.
Whether you need a simple single-layer board or a high-density multilayer design, we provide top-tier PCB design services customized to your specific requirements. Our designs prioritize signal integrity, thermal performance, and cost-effective manufacturing — ensuring your product meets both functional and commercial goals.
PCB (Printed Circuit Board) designing is the process of translating a circuit schematic into a physical layout that can be manufactured and assembled. It involves strategic placement of components, routing of copper traces, and layering of conductive and insulating materials — all while ensuring electrical performance and manufacturability.
Key stages in PCB designing include:
Logical design of circuit components and connections
Precise arrangement of components and routing paths.
Verification against manufacturing constraints.
Output files used for PCB fabrication.
| Specification | Details |
|---|---|
| Layers | 1 to 20 |
| Board Type | Rigid, Flex, Rigid-Flex |
| Trace Width/Spacing | As low as 3 mils |
| Impedance Control | Supported |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver |
Experience the perfect blend of reliability and precision with our high-performance PCB Designing
| Feature | Cutek Circuits | Standard Designers |
|---|---|---|
| Signal Integrity | Optimized for high-speed & EMI | Basic routing |
| Customization | Full stack design-to-manufacture | Limited integration |
| Prototyping Speed | 3–5 days for small boards | 7–10 days |
| Compliance | IPC & RoHS certified | Varies |
| Design Review | Multi-point checks & simulations | Minimal validation |
Rigorous quality checks and industry-standard certifications ensure every PCB meets the highest performance and reliability standards:
Our standard turnaround time is 3–5 working days for prototype designs. Complex or multilayer boards may take slightly longer depending on requirements.
Yes, we specialize in high-speed digital and RF PCB designs with impedance control, signal integrity optimization, and EMI/EMC compliance.
Absolutely. All our PCB layouts undergo thorough DFM and DFT checks to ensure ease of manufacturing and post-production testing.
Yes, we offer full BOM preparation and can support component selection and sourcing to match your budget and lead time.
You'll receive Gerber files, drill files, BOM, pick-and-place files, and 3D models — everything needed for fabrication and assembly.
Yes, we design multilayer PCBs with up to 20+ layers, optimized for signal integrity, power distribution, and compact form factors in complex applications.
